Name: P10 Rgb Led Display Module / 16x16 Led Matrix Display SMD1515 / SMD5050
Brand: P10 Rgb Led Display Module / 16x16 Led Matrix Display SMD1515 / SMD5050
SKU: P10 Rgb Led Display Module / 16x16 Led Matrix Display SMD1515 / SMD5050
Price: 400 USD
Availability: InStock
Rating: 4.6 (191 reviews)

Home Products SMD1515 LED Display

P10 Rgb Led Display Module / 16x16 Led Matrix Display SMD1515 / SMD5050

Product Details:

Place of Origin:	China
Certification:	CE, CCC, FCC, ROSH, ISO9001

Payment & Shipping Terms:

Minimum Order Quantity:	1pcs
Price:	USD 400-1999 per sqm
Packaging Details:	Flight case or wooden case
Delivery Time:	within 15 to 20 working days after receiving deposit
Payment Terms:	T/T, Western Union
Supply Ability:	1300 square meters per month

Contact Now

Detailed Product Description

Production Name:	SMD LED Screen	Tech:	SMD
Size:	160*160mm	Brightness:	5000cd/㎡
Pixels:	P10	Usage:	Airport\|stage
Function:	Advertisement\|message\|picture	Feature:	Full Color
High Light:	smd led display screen , full color led display

P10 Rgb Led Display Module / 16x16 Led Matrix Display SMD1515 / SMD5050

Function:

Excellent visual effect, clear and exquisite
Good flatness.
Easy to clean, welding spots inoxidizable.
Closer look available, better effects without glare and mosaic.
Good viewing angle.
Easy to assembly, install and transport with simple packing and convenient use.
Vivid mixed colors.
No color cast when look from different angles.
Excellent heat-sinking, high stability, no scrapped lamp.

Product Application:

Wide applied in stadiums,advertisement,banks,securities exchange,stations,shoping malls,postal officees,schools,monitoring,restaurants,entertainment,enterprises etc...

Specifications:

Product type	P10
Pixel pitch	10mm
Pixel constitution	1R1G1B
LED package mode	SMD1515 / SMD5050
Pixel density	10000dots/㎡
Scan mode	4
Brightness	5000cd/㎡ / 5500cd/㎡
Module resolution	16*16
Module size	160*160mm
Max. consumption	800W/㎡
Ave. consumption	320W/㎡
Viewing angle	Horizontal 120°/Vertical 100°
Cabinet	Customized (size, color, design etc.)
Control Method	Synchronous
Frame frequency	≧ 60Hz
Refresh Rate	≧ 400Hz,Max. 2000Hz
Grey level	≧ 4K grade
Brightness adjustment	Manual or Auto 100 grade
Working temperature	-10 OC — +45 OC
Working voltage	AC220V±10%；50Hz(AC110V optional)
Video interface	VGA,DVI,CVBS,Y/C,YPbPr,SDI/HDSDI,HDMI etc
Communication distance	Network cable≦100m; Multimode Fiber≦500m; Single mode Fiber≦10km
Average fault-free	5000hours
Life span	100000hours
Defect ratio	≦0.1‰
control system	DVI display card + full color controller card

Competitive Advantage:

1) Price Advantage: Best competitive price of the market.
2) Performance Advantage: Best brightness, High refresh rate, high consistency, Big viewing angle...

3) Quality advantage: From material to finished product, from design to produce, we control all steps, that's the guarantee of the quality and reliability.
4) Service advantage: with professional service team for 24 hours service!

FAQ

Q1:LED display models are generally expressed in PX, such as P2 P3 P4.....P8, P10, what does this mean?
A: P3 P4.....P8,P10 means that the pixel pitch is 3mm 4mm....10mm, which determines resolution of a display .Pixel pitch is smaller, led display resolution is higher.

Q2:What pixel pitch should I choose on my display?
A: it is determined mainly by the viewing distance, the size of the display screen, the desired effect and the customer budget.

Q3: To order a display ,What kind of information do I have to offer you?
A:You should provide width/height of the display size, the main use, the viewing distance, the scene photos, special requirements,then I can provide you with a detailed list of quotations.

Q4:How to install?
A:Free of charge to provide detailed steel structure drawings and installation guidance and wiring diagram, free remote debugging.

Q5:What about your quality?
A:The quality of our display is excellent. We use the materials of high quality suppliers in the world, strictly control the production process, and pass the multiple quality inspection to ensure that every product is qualified.

P10 Rgb Led Display Module / 16x16 Led Matrix Display SMD1515 / SMD5050
