| Place of Origin: | China |
| Certification: | CE, CCC, FCC, ROSH, ISO9001 |
| Minimum Order Quantity: | 1pcs |
|---|---|
| Price: | USD 400-1999 per sqm |
| Packaging Details: | Flight case or wooden case |
| Delivery Time: | within 15 to 20 working days after receiving deposit |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 1300 square meters per month |
| Features: | Waterproof | Screen Dimension: | Customized |
|---|---|---|---|
| Led Chip: | Epistar | Best Viewing Distance: | 10m |
| Pixel Configuration: | 1R1G1B DIP346 | Pixel Pitch: | 10mm |
| View Angle: | 110° | ||
| High Light: | p10 led display,led display screens |
||
Event Real Pixel Rgb P10 Led Display Module 10mm Pixel Pitch Led Video Display
Power, signal indicators in the power box.
Approved by RoHS certification, Lead-free, enviromental design
Ergonomic handle design, convenient handling
High performance and adjustable side lock.
International standards air plug on Power connectors, easy, fast and safe.
Receiving card to card with LAN cable, simple, less failure rate
Technical Parameters:
The main parameter
|
P10 Full Color Display |
|
|
Physical Pixel Pitch |
10mm |
|
Module Size |
160*160mm |
|
Pixel Density |
10000/㎡ |
|
Pixel Configuration |
1R1G1B DIP346 |
|
Best Viewing Distance |
10m |
|
View Angle(Horizontal) |
110° |
|
Brightness |
≥7000cd/㎡ |
|
Driving Method |
1/4 Constant Driving |
|
Control Mode |
Real Pixel |
|
Cabinet Size |
640*480mm |
|
Cabinet Resolution |
64*48 |
|
Cabinet Weight |
32kg |
|
Maximum Power Consumption |
920W/㎡ |
|
Operating Voltage |
220±10% or 110±10% |
