Advertising P5 Super Slim Led Display High Definition 360000dots/M2

Product Details:

Place of Origin:	China
Certification:	CE, CCC, FCC, ROSH, ISO9001

Payment & Shipping Terms:

Minimum Order Quantity:	1pcs
Price:	USD 400-1999 per sqm
Packaging Details:	Flight case or wooden case
Delivery Time:	within 15 to 20 working days after receiving deposit
Payment Terms:	T/T, Western Union
Supply Ability:	1300 square meters per month

Contact Now

Detailed Product Description

Pixel Pitch:	PH4mm	Encapsulation:	SMD2121
Color:	Full Color	Cabinet:	Die-casting Aluminum Alloy
View Angle:	140°(Horizontal )/140°(Vertical )	Working Voltage:	AC 220V/110V S±15% 50-60 HZ
High Light:	p5 led display , ultra thin led screen

Advertising P5 Super Slim Led Display High Definition 360000dots/M2

Product details

Unit Module	Part No	P1.667-LC-30S
	Pixel pitch	1.667mm
	Module size	200mm*100mm
	Tube chip color	full color
	Pixel Density	360000dots/m2
	led combination	1R1G1B
	Module resolution	128*64dots
	Module weight	0.4kg
main technical parameters	Scan method	1/30s
	refresh rate	≥3840Hz
	Brightness of white balance	≥1200cd/m2
	cabinet resolution	256mm*192mm
	cabinet size	400mm*300mm
	Best view distance	2m−15m
	Best view angle	160°(W)*160°(H)
	Storage temperature	−35℃-+85℃
	Working temperature	−20℃-+50℃
	working voltage	AC110/220V±10%
	Average power consumption	≤233W/m2
	Max power consumption	≤900W/m2
	brightness adjustment method	Brightness induction automatic adjustment
	Frame Frequency	50&60HZ
	Luminance Level/color	RGB256
	Gray Level	16384 grade
	MTBF	≥5000hrs
Control system	Display card	DVI graphics
	Control method	Synchronization
	Operation syetem	WIN98,WINXP,WIN2000,etc
	display sign	RF,S-Video,RGB,RGBHV,YUV, YC,COMPOSITION, etc

Features:

1. seamless assembling, less than 1mm.

2. High-definition visual effect.

3. High thermal conductivity Alloy cabinet, better heat dissipation

4. Fan-free design, energy saving, more stable,

5. 140〫 degree wilde view angle

6. Power, signal indicators in the power box.

7. Approved by RoHS certification, Lead-free, enviromental design

8. Ergonomic handle design, convenient handling

9. High performance and adjustable side lock.

10. International standards air plug on Power connectors, easy, fast and safe.

11. Receiving card to card with LAN cable, simple, less failure rate

Training:

In order to let our customers control the system skillfully, and easily handle some basic malfunction or system failure in the operation. We offer our users a training course in the following two steps:

1. Factory training with the follow course:

Basic computer knowledge
Basic LED knowledge
LED hardware structure and working principle
Screen programming and all the software demonstration
System daily maintenance and safety regulations

2. On-site training

The installation of system software
The function of apparatus in system and the method of the right usage
The inspection, adjustment and test of apparatus and the measurement tools common use and instrumental usage
The apparatus protection instructions
Ordinary software & hardware malfunction disposal
