480x480 P5 Super Slim Led Display Die casting Aluminum Alloy Cabinet

480x480 P5 Super Slim Led Display Die casting Aluminum Alloy Cabinet

    • 480x480 P5 Super Slim Led Display Die casting Aluminum Alloy Cabinet
    • 480x480 P5 Super Slim Led Display Die casting Aluminum Alloy Cabinet
    • 480x480 P5 Super Slim Led Display Die casting Aluminum Alloy Cabinet

    Product Details:

    Place of Origin: China
    Certification: CE, CCC, FCC, ROSH, ISO9001

    Payment & Shipping Terms:

    Minimum Order Quantity: 1pcs
    Price: USD 400-1999 per sqm
    Packaging Details: Flight case or wooden case
    Delivery Time: within 15 to 20 working days after receiving deposit
    Payment Terms: T/T, Western Union
    Supply Ability: 1300 square meters per month
    Contact Now
    Detailed Product Description
    Pixel Pitch: PH2.5mm Encapsulation: SMD2121
    Color: Full Color Cabinet: Die-casting Aluminum Alloy
    Cabinet Size: 480x480mm View Angle: 140°(Horizontal )/140°(Vertical )
    LED Lifespan: 100,000 Hours Working Voltage: AC 220V/110V S±15% 50-60 HZ
    Viewing Distance: 2-75 Meters
    Highlight:

    p5 led display

    ,

    led stage screen rental

    480x480 P5 Super Slim Led Display Die casting Aluminum Alloy Cabinet​





    Specifications:



    Pixel Pitch 2.5mm
    Pixel Package SMD2121
    LED Configuration 1R1G1B
    Pixel Density 160000 Pixels/㎡
    Module Size 160mm x 160mm
    Module Resolution 64 x 64 dots
    Suggested Cabinet Size 480mm x 480mm x 64mm
    Cabinet Resolution 192 x 192 dots
    Cabinet Material Die-casting Aluminum Alloy
    Cabinet Weight 7.1 kg/panel
    Brightness 1000-2000 nits
    Color Temperature 3000-12000K
    Viewing Angle H-140°/ V-140°
    Driving Mode 1/32
    Refresh Rate 1920-3840Hz
    Frame Frenquency 60Hz
    Grey Level 4096-16384
    Number of Color 1 billion
    Input Maximum Power 1300 W/㎡
    Input Voltage AC220±10%, AC110 ±10%
    Input Frequency 50-60Hz
    External Interface S-video, VGA, DVI, SDI, CVBS, YPrPb, HDMI, etc
    IP Rating IP43


    Features:



    1. seamless assembling, less than 1mm.



    2. High-definition visual effect.



    3. High thermal conductivity Alloy cabinet, better heat dissipation



    4. Fan-free design, energy saving, more stable,



    5. 140〫 degree wilde view angle



    1. High,SMD black ligth +black mask,showing a high contrast,better visual effects.

    2. High -end S--PWM IC driver,high refresh,high grayscale,high brightness,no blur.

    3. Single point brightness,color correction,color consistency is preferrred.

    4. Board to board connector design,no link cable,improve stability,easy installation and

    disassembly maintenance.

    5. Easy front maintenance,a screw,a tool to complete.



    480x480 P5 Super Slim Led Display Die casting Aluminum Alloy Cabinet480x480 P5 Super Slim Led Display Die casting Aluminum Alloy Cabinet
